INVERT YOUR THINKING!
The CENTURION A10 Industrial Slide Gate Motor.
A10 – INDUSTRIAL SLIDING GATE MOTOR
Capable of handling sliding gates up to two tonnes in mass, and in arduous operating conditions, the automatic choice for commercial and industrial applications is the A10 industrial sliding gate motor. The CENTURION A10 uses a three-phase AC motor and electronic inverter to provide ultra rapid opening and closing of the gate. The speed can be increased from 16 up to 30 metres per minute and is adjustable between opening and closing. The inverter’s added advantage of total speed control, makes for the fastest, smoothest starting and stopping of any sliding gate on the market in addition to extending the long-term reliability of the system. Combining the running characteristics of the three-phase motor and the efficiency of the inverter, the A10 industrial sliding gate motor continues to run cool even in high-duty applications. Although the A10 uses a three-phase motor, thanks to the inverter, it still connects to a standard 220V AC single-phase supply making the unit the ideal gate motor for virtually any domestic and industrial application. The clever design of the mechanical aspects makes installation quick and easy. In addition to the already exceptional benefits of the standard A10 industrial sliding gate motor, an optional DC converter module can be added to give battery backup. Solar power can be used to recharge the batteries enabling even the most remote sites to enjoy the security and convenience provided by the automatic choice in sliding gate motors.
High push force.
High duty cycle capability.
Extremely rapid operating speed.
Intelligent and smooth speed control.
Multiple programmable features.
Optional DC Converter for reliable battery backup.
On-demand battery backup protection.
Brown-out power failure detection.
Integrated battery charger.
Be alerted of gate activity via SMS by connecting a CENTURION GSM device.
- A10 Endurance – A rapid and robust operator for commercial and industrial gates up to 1000kg.
- A10 Heavyweight – An all round performer for gates up to 2000kg.
A10 TECHNICAL DATA
|A10 ENDURANCE||A10 HEAVYWEIGHT|
|Input Voltage||220 - 240V AC +/- 10%, 50Hz [*] (single phase)||220 - 240V AC +/- 10%, 50Hz [*] (single phase)|
|Motor Voltage||380V AC Three-Phase||380V AC Three-Phase|
|Push Force - Rated - Standard Speed||30kgf||30kgf|
|Push Force - Rated - Sprint Speed||22.5kgf||NA|
|Gate Speed at Rated Push Force - Standard Speed||16m/min||13.6m/min|
|Gate Speed at Rated Push Force - Sprint Speed||30m/min||NA|
|Duty Cycle||80% [**]||80% [**]|
|Gate Mass - Max - Standard Speed||1000kg||2000kg|
|Gate Mass - Max - Sprint Speed||600kg||NA|
[*] – Can operate off a solar supply, consult Centurion Systems for assistance. [*] – Based on a pull force of less than 50% of rated. [**] – Based on 25°C ambient temperature and unit not in direct sunlight.
