Automatic 24V Hybrid Barrier
Safe performance and reliability
The B680H has a Hybrid heart which, together with its “everlasting” springs, allows it to exceed 2,000,000 cycles of continuous use, raising an 8m pole in less than 6 seconds, in total safety, thanks to the reverse-on-contact feature.
The B680H has an internal load-bearing structure and an external removable housing. This design gives the system great stability and permits easy replacement of the housing.
Extreme flexibility and optimisation of logistics
One single model controls passages with a net width from 2m to 8m. Its modular boom pole makes the B680H a product which is easy to manage and handle.
Full visibility and control of traffic
The programmable integrated flashing traffic light connector guarantees perfect regulation of traffic, while the LED beam lights signal the closing of the passage even under conditions of poor visibility.
Switching power supply
The switching power supply, with high energy efficiency and extended range, ensures operation of barriers from 100V AC to 240V AC, protecting the system against any fluctuations in voltage occurring with non-optimal power supply systems.
Integrated absolute encoder
Absolute encoder kit for complete control of movement and reversing of the boom pole when an obstacle is detected, ensuring that pedestrian passages also comply with safety standards.
The springs of the B680H have been designed to exceed 2,000,000 cycles.
Installing the XBAT 24 module (high-performance Nickel-Metal Hydride batteries), including battery charger, ensures the operation of the B680H even during a power failure:
- 2,000,000 cycles thanks to the Brushless + Hydraulic motor and “unlimited” springs
- Removable cabinet available in 4 colours or stainless steel
- High logistic optimisation: a single barrier model suitable for all boom pole lengths
