D20 SMART sliding gate motor for heavy gates

When it’s time to beef up security, you need real muscle, the kind that only the number one in access automation can deliver. Introducing the brand new D20 SMART industrial sliding gate motor. If your high-volume site calls for the kind of security that never backs down even when it’s pushed beyond the limits of other gate motors, make the intelligent choice and get the D20 SMART.

Main features:

  • Strong enough to move a 2t gate
  • Easy “drop-in” replacement for existing A10 sites
  • SMART technology makes the D20 SMART as intelligent as it’s solid
  • Installer-friendly design with easy access to mounting hardware, optimised cable routing and a dedicated accessory tray
  • Smooth and strong
  • Alert and agile – highly reliable Hall Effect technology keeps track of the gate position at all times, and ensures pin-point stopping

Technical Specifications:

Input voltage 90V - 240V AC +/-10% @ 50Hz1
Current consumption (Mains) 250mA
Battery charger current output 1.8A @ 27.4V +/-1%
Maximum number of operations per day 750.2, 5
Duty cycle - Mains present2, 3 45%
Motor voltage 24V DC
Motor power supply Battery-driven (Standard Capacity - 2x 7.2Ah)3
Current consumption (motor at rated load) 9A
Input / Output sink currents (Max accessory current draw)
I/O 1-4 100mA (12/24V)
I/O 5 and 6 3A (12/24V) 10sec Pulse
Motor push force - starting 52kgf
Motor push force - rated 39kgf
Gate mass - maximum 2000kg
Gate length - maximum 25m
Gate speed (varies with load)2, 5 Up to 18m/min3
Manual Override Lockable lever with key release
Drive Pinion 13T Module 4
Operations in standby with 2x 7.2Ah batteries Power Saving (15m/min 20kgf) | Normal (18m/min 20kgf)
Half day2, 3, 4 101 | 55
Full day2, 3, 4 80 | 45
Collision Sensing Electronic
Operating temperature range -15°C to +50°C
Onboard receiver type CENTURION rolling code (Keeloq encryption) multichannel
Receiver code storage capacity 1500 Remotes6
Receiver frequency 433.92MHz
Degree of protection IP54
Mass of unit packed (with standard kit, but excl. rack and battery) 13Kg
Packaging dimensions (with standard kit, but excl. rack and battery) 350mm wide x 282mm deep x 470mm high

1. Can operate off a solar supply, consult your local dealer for assistance
2. Based on 25°C ambient temperature and unit not in direct sunlight
3. Based on a motor push force of less than 50% of rated (Starting and Running forces)
4. Gate opening and closing speeds can be configured to run slower depending on the
requirements of individual installations
5. Can increase battery capacity for longer standby times
6. Based on 4m gate, excluding all accessories
7. Multiple buttons per remote can be used
